Crush Guard - Installation - Haulotte HA16PE/HA18PX Finalisation

Crush Guard - Installation - Haulotte HA16PE/HA18PX Finalisation

Notes
This Tech Doc shows how to finalise the installation on the Haulotte HA16PE/HA18PX Boom Lift
Installation Steps:
1. Place the lid back onto the operator control box and tighten the 4 bolts that secure the lid.


2. Connect the M23 connector from the Control Module to the socket installed in the operator control box.
3. Make sure that the connector is screwed up finger tight.


4. Inspect the entire Crush Guard installation, make sure that all bolts, connectors and cables are secure.
5. Make sure that the machine is fit for operation.
